5d492744ce7e2310c3f5e7dc Single Board Computers Rock960 Board - Based on the RK3399 SoC - C Version https://www.tenettech.com/s/59c9e4669bd3e7c70c5f5e6c/ms.products/5d492744ce7e2310c3f5e7dc/images/5d492744ce7e2310c3f5e7e0/5d492655ce7e2310c3f5c744/5d492655ce7e2310c3f5c744.jpg

Description

ROCK960 model C, the new ROCK960 model.

We also support Rock 960 2G RAM Version and Rock 960 4G RAM Version.

ROCK960 Models Comparison Table

Technical details

Dimensions 85mm x54mm x15mm
Weight G.W 120g
Battery Exclude
SoC Rochchip RK3399 hexa-core, ARM Cortex A72 cores up to 1.8/2.0 GHz, four Cortex A53 cores @ 1.4 GHz
Support ARM Mali-T860 MP4 GPU with OpenGL ES 1.1 to 3.2 support, OpenVG1.1, OpenCL 1.2 and DX 11 support
System Memory 1G RAM
Storage None eMMC + micro SD card
Video Output 1x HDMI 2.0 up to 4K@60 Hz with CEC and HDCP
Connectivity WiFi 802.11ac 2×2 MIMO up to 867 Mbps, and Bluetooth 4.1 LE (AP6356S module) with two on-board antennas, two u.FL antenna connectors
USB 1x USB 2.0 host port, 1x USB 3.0 port, 1x USB 3.0 type C port with DP 1.2 support
TT-SDK-102060065
in stock INR
SEEEDSTUDIO
1 1
Single Board Computers Rock960 Board - Based on the RK3399 SoC - C Version

Single Board Computers Rock960 Board - Based on the RK3399 SoC - C Version

Sku: TT-SDK-102060065
Be the first to review this product
Product Enquiry
Contact Seller Contact Seller
Sold By: tenettech

Description of product

Description

ROCK960 model C, the new ROCK960 model.

We also support Rock 960 2G RAM Version and Rock 960 4G RAM Version.

ROCK960 Models Comparison Table

Technical details

Dimensions 85mm x54mm x15mm
Weight G.W 120g
Battery Exclude
SoC Rochchip RK3399 hexa-core, ARM Cortex A72 cores up to 1.8/2.0 GHz, four Cortex A53 cores @ 1.4 GHz
Support ARM Mali-T860 MP4 GPU with OpenGL ES 1.1 to 3.2 support, OpenVG1.1, OpenCL 1.2 and DX 11 support
System Memory 1G RAM
Storage None eMMC + micro SD card
Video Output 1x HDMI 2.0 up to 4K@60 Hz with CEC and HDCP
Connectivity WiFi 802.11ac 2×2 MIMO up to 867 Mbps, and Bluetooth 4.1 LE (AP6356S module) with two on-board antennas, two u.FL antenna connectors
USB 1x USB 2.0 host port, 1x USB 3.0 port, 1x USB 3.0 type C port with DP 1.2 support
