The GM861 barcode scanner offers UART and USB interfaces, capable of reading both QR codes and barcodes with its CMOS sensor and 640×480 scan resolution. A green LED indicates successful reads. It supports 1D and 2D codes with a reading distance of 5-30cm and a scan angle of 360° roll, 65° pitch, and 65° yaw. Compact and efficient, it operates at 3.3V and consumes 70mA max current.

Features:

1. Dual UART and USB interfaces
2. CMOS sensor with 640×480 resolution
3. Green LED indicator for successful reads
4. Reads both 1D and 2D codes
5. 5-30cm reading distance
6. Compact size and lightweight design
7. Read Code Type:
8. 1D: EAN-13, EAN-8, UPC-A, UPC-E ISSN, ISBN, CodaBar,Code 128, Code93, ITF-14, ITF-6, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 39,Code 11, MSI-Plessey, GS1 Composite,GS1-Databar (RSS)

Package Includes:

1 x GM861 Barcode scanner
