ESP8285 Nodemcu Development Board

ESP8285 Nodemcu Development Board

Sku: TT-DTK-2081

Sold By: tenettech
  • Shipping in 10-12 Working days

Description of product


This is a NodeMcu based on ESP8285 module. Yes not ESP8266 or ESP32 this module is based on ESP8285-M2 chipset.

The chip integrates the enhanced version of the Tensilica's L106 Diamond 32-bit core processor with on-chip SRAM in a smaller package. ESP8285 has a complete Wi-Fi network function, both can be used independently, can also be used as a slave from other host MCU running. When the ESP8285 hosting application, can be started directly from the external Flash. Built-in cache memory facilitates system performance and optimizes storage systems. In addition, ESP8285 only through the SPI / SDIO interface or I2C / UART port can be used as a Wi-Fi adapter, applied to any microcontroller-based design.

Features Of Nodemcu ESP8285-M2 CH340

  • The volume is ultra-small;
  • Serial to WiFi;
  • Wireless transmission;
  • Long-range ultra-low power consumption;
  • High temperature, up to 125 ℃
  • Fully compatible with ESP8266, the source can be used to transplant.

Characteristics Of Nodemcu ESP8285-M2 CH340

  • Built-in Tensilica L106 ultra-low power 32-bit microprocessor, clocked at 80MHz and 160MHz support RTOS
  • Built-in TCP / IP protocol stack
  • Built-in 1-channel 10-bit high-precision ADC
  • Peripheral Interface HSPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO
  • The deep sleep hold current is 10uA and the shutdown current is less than 5uA
  • Wake up within 2 ms, connect and pass the packet
  • Standby power consumption less than 1.0mW (DTIM3)
  • Built-in 1M bytes of SPI Flash

Wi-Fi features Of Nodemcu ESP8285-M2 CH340

  • Supports 802.11 b / g / n / e / i
  • Support Station, SoftAP, SoftAP + STA mode
  • Support for Wi-Fi Direct (P2P)
  • Supports CCMP (CBC-MAC, counter mode), TKIP (MIC, RC4), WAPI (SMS4), WEP (RC4), CRC hardware acceleration
  • P2P discovery, P2P GO mode / GC mode and P2P power management
  • WPA / PA2 PSK and WPS
  • 802.11 i security features: pre-authentication and TSN
  • Hold 802.11n (2.4 GHz)
  • 802.1h / RFC1042 frame encapsulation
  • Seamless roaming support
  • Support AT remote upgrade and cloud OTA upgrade
  • Support for Smart Config features (including Android and iOS devices)
  • Operating temperature range: -40 ℃ -125 ℃

Applications Of Nodemcu ESP8285-M2 CH340

  • Household appliances
  • Home automation
  • Smart socket, smart light
  • Mesh network
  • Baby monitor
  • IP camera
  • sensor network
  • can wear electronic products
  • Security ID tag
  • Wireless location awareness
  • Wireless positioning system beacon
  • Industrial wireless control
