Series | - |
Product Status | Active |
Color | Red, Green, Blue (RGB) |
Configuration | Independent |
Lens Color | - |
Lens Transparency | Diffused |
Millicandela Rating | 710mcd Red, 1840mcd Green, 410mcd Blue |
Lens Style | Round with Flat Top |
Lens Size | - |
Voltage - Forward (Vf) (Typ) | 2.1V Red, 2.9V Green, 2.9V Blue |
Current - Test | 20mA |
Viewing Angle | 110° |
Mounting Type | Surface Mount |
Wavelength - Dominant | 620nm Red, 524nm Green, 471nm Blue |
Wavelength - Peak | 628nm Red, 518nm Green, 467nm Blue |
Features | - |
Package / Case | 6-PLCC |
Supplier Device Package | 6-PLCC |
Size / Dimension | 3.70mm L x 3.50mm W |
Height (Max) | 3.00mm |
Series | - |
Product Status | Active |
Color | Red, Green, Blue (RGB) |
Configuration | Independent |
Lens Color | - |
Lens Transparency | Diffused |
Millicandela Rating | 710mcd Red, 1840mcd Green, 410mcd Blue |
Lens Style | Round with Flat Top |
Lens Size | - |
Voltage - Forward (Vf) (Typ) | 2.1V Red, 2.9V Green, 2.9V Blue |
Current - Test | 20mA |
Viewing Angle | 110° |
Mounting Type | Surface Mount |
Wavelength - Dominant | 620nm Red, 524nm Green, 471nm Blue |
Wavelength - Peak | 628nm Red, 518nm Green, 467nm Blue |
Features | - |
Package / Case | 6-PLCC |
Supplier Device Package | 6-PLCC |
Size / Dimension | 3.70mm L x 3.50mm W |
Height (Max) | 3.00mm |
