Series | Multi TOPLED® |
Product Status | Active |
Color | Green, Red |
Configuration | Independent |
Lens Color | Colorless |
Lens Transparency | Clear |
Millicandela Rating | 68mcd Green, 118mcd Red |
Lens Style | Round with Flat Top |
Lens Size | 2.40mm Dia |
Voltage - Forward (Vf) (Typ) | 2V Green, 2V Red |
Current - Test | 20mA Green, 20mA Red |
Viewing Angle | 120° |
Mounting Type | Surface Mount |
Wavelength - Dominant | 570nm Green, 633nm Red |
Wavelength - Peak | 572nm Green, 645nm Red |
Features | - |
Package / Case | 4-PLCC |
Supplier Device Package | 4-PLCC |
Size / Dimension | 3.20mm L x 2.80mm W |
Height (Max) | 2.10mm |
Series | Multi TOPLED® |
Product Status | Active |
Color | Green, Red |
Configuration | Independent |
Lens Color | Colorless |
Lens Transparency | Clear |
Millicandela Rating | 68mcd Green, 118mcd Red |
Lens Style | Round with Flat Top |
Lens Size | 2.40mm Dia |
Voltage - Forward (Vf) (Typ) | 2V Green, 2V Red |
Current - Test | 20mA Green, 20mA Red |
Viewing Angle | 120° |
Mounting Type | Surface Mount |
Wavelength - Dominant | 570nm Green, 633nm Red |
Wavelength - Peak | 572nm Green, 645nm Red |
Features | - |
Package / Case | 4-PLCC |
Supplier Device Package | 4-PLCC |
Size / Dimension | 3.20mm L x 2.80mm W |
Height (Max) | 2.10mm |
