66aa282d48eccef468bfbcb2 Mallory Sonalert Products Inc. 458-1369-ND https://www.tenettech.com/s/59c9e4669bd3e7c70c5f5e6c/66aa282e48eccef468bfbcbe/mso320sr.jpg

BUZZER PIEZO 23X23MM TH

Product Attributes:

Series MSO
Product Status Active
Driver Circuitry Indicator, Internally Driven
Input Type DC
Voltage - Rated -
Voltage Range 3 ~ 20V
Frequency 3.5kHz
Technology Piezo
Operating Mode Single Tone
Duration -
Sound Pressure Level (SPL) 73dB @ 3V, 30cm
Current - Supply 3 ~ 16mA
Port Location Top
Operating Temperature -20°C ~ 65°C
Approval Agency -
Ratings Washable
Mounting Type Through Hole
Termination PC Pins
Size / Dimension 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) 0.535" (13.60mm)
Ingress Protection -
TT-DKEY-458-1369-ND
in stock INR
Mallory Sonalert Products Inc.
1 1
Mallory Sonalert Products Inc. 458-1369-ND

Mallory Sonalert Products Inc. 458-1369-ND

Sku: TT-DKEY-458-1369-ND
Be the first to review this product
Product Enquiry
Contact Seller Contact Seller
Sold By: tenettech
Features
  • Shipping in 10-12 Working Days

Description of product

BUZZER PIEZO 23X23MM TH

Product Attributes:

Series MSO
Product Status Active
Driver Circuitry Indicator, Internally Driven
Input Type DC
Voltage - Rated -
Voltage Range 3 ~ 20V
Frequency 3.5kHz
Technology Piezo
Operating Mode Single Tone
Duration -
Sound Pressure Level (SPL) 73dB @ 3V, 30cm
Current - Supply 3 ~ 16mA
Port Location Top
Operating Temperature -20°C ~ 65°C
Approval Agency -
Ratings Washable
Mounting Type Through Hole
Termination PC Pins
Size / Dimension 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) 0.535" (13.60mm)
Ingress Protection -
