Texas Instruments 296-CC1352P1F3RGZRTR-ND,296-CC1352P1F3RGZRCT-ND,296-CC1352P1F3RGZRDKR-ND
Sku: TT-DKEY-296-CC1352P1F3RGZRTR-ND,296-CC1352P1F3RGZRCT-ND,296-CC1352P1F3RGZRDKR-ND
₹1,186.56
Features
- Shipping in 10-12 Working Days
Description of product
IC RF TXRX+MCU BLE 5.1 48VQFN
Product Attributes:
| Series | SimpleLink™ |
| Product Status | Active |
| Type | TxRx + MCU |
| RF Family/Standard | 802.15.4, Bluetooth |
| Protocol | 6LoWPAN, Bluetooth v5.1, Thread, Zigbee® |
| Modulation | DSSS, GFSK, O-QPSK |
| Frequency | 143MHz ~ 176MHz, 287MHz ~ 351MHz, 359MHz ~ 527MHz, 861MHz ~ 1.054GHz, 1.076GHz ~ 1.315GHz, 2.36GHz ~ 2.5GHz |
| Data Rate (Max) | 2Mbps |
| Power - Output | 20dBm |
| Sensitivity | -122dBm |
| Memory Size | 352kB Flash, 80kB SRAM |
| Serial Interfaces | ADC, GPIO, I2C, I2S, SPI, UART |
| GPIO | 26 |
| Voltage - Supply | 1.8V ~ 3.8V |
| Current - Receiving | 5.8mA |
| Current - Transmitting | 63mA ~ 79mA |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 48-VFQFN Exposed Pad |
| Supplier Device Package | 48-VQFN (7x7) |
| DigiKey Programmable | Not Verified |
| Grade | - |
| Qualification | - |
