Series | CMC |
Product Status | Active |
Type | Electret Condenser |
Output Type | Analog |
Direction | Omnidirectional |
Frequency Range | 100 Hz ~ 20 kHz |
Sensitivity | -25dB ±3dB @ 94dB SPL |
S/N Ratio | 62dB |
Voltage - Rated | 3 V |
Current - Supply | 500 µA |
Port Location | Top |
Ratings | - |
Termination | Solder Pads |
Size / Dimension | 0.157" Dia (4.00mm) |
Height (Max) | 0.067" (1.70mm) |
Shape | Circular |
Impedance | 2.2 kOhms |
Voltage Range | 3 V ~ 10 V |
Grade | - |
Qualification | - |
Series | CMC |
Product Status | Active |
Type | Electret Condenser |
Output Type | Analog |
Direction | Omnidirectional |
Frequency Range | 100 Hz ~ 20 kHz |
Sensitivity | -25dB ±3dB @ 94dB SPL |
S/N Ratio | 62dB |
Voltage - Rated | 3 V |
Current - Supply | 500 µA |
Port Location | Top |
Ratings | - |
Termination | Solder Pads |
Size / Dimension | 0.157" Dia (4.00mm) |
Height (Max) | 0.067" (1.70mm) |
Shape | Circular |
Impedance | 2.2 kOhms |
Voltage Range | 3 V ~ 10 V |
Grade | - |
Qualification | - |
