Grove - HCHO Sensor

Sku: TT-SS-101020001

Sold By: tenettech
  • Shipping in 10-12 Working days

Description of product


The Grove - HCHO Sensor is a semiconductor VOC gas sensor. It uses the VOC sensor WSP2110 whose conductivity changes with the concentration of VOC gas in air. With a circuit, the conductivity can be converted to an output signal that corresponds to the gas concentration. This sensor has a very high sensitivity and stability, it can detect the gas whose concentration is up to 1ppm. It can be used to detect Toluene, Methanal, Benzene, Alcohol, Acetone etc. This product can be used to detect the presence of harmful gas in the home environment. It can be a good assistant to improve indoor air quality.

  • Operating Voltage: 5.0V ± 0.3V

  • Target Gases: HCHO, Benzene,Toluene, Alcohol

  • Concentration Range: 1~50 ppm

  • Sensor Resistance Value(Rs): 10KΩ-100KΩ(in 10ppm HCHO)

  • Sensitivity: Rs(in air)/Rs(10ppm HCHO)≥5

Technical Details

Dimensions 120mm x 85mm x 11mm
Weight G.W 7g
Battery Exclude

Part List

Grove - HCHO Sensor 1
Grove - cable 1
