5f731974b0453226f3c15695 ARDUINO MICRO WITHOUT HEADERS https://cdn1.storehippo.com/s/59c9e4669bd3e7c70c5f5e6c/5f7318e93c9ba8889d4294ba/webp/a000093_bexp.jpg

The Micro is a microcontroller board based on the ATmega32U4 (datasheet), developed in conjunction with Adafruit. It has 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a micro USB connection, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a micro USB cable to get started. It has a form factor that enables it to be easily placed on a breadboard.

 The Micro board is similar to the Arduino Leonardo in that the ATmega32U4 has built-in USB communication, eliminating the need for a secondary processor. This allows the Micro to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial / COM port. It also has other implications for the behavior of the board.

Microcontroller ATmega32U4
Operating Voltage 5V
Input Voltage (recommended) 7-9V
Input Voltage (limit) 6-9V
Digital I/O Pins 20
PWM Channels 7
Analog Input Channels 12
DC Current per I/O Pin 20 mA
DC Current for 3.3V Pin 50 mA
Flash Memory 32 KB (ATmega32U4) of which 4 KB used by bootloader
SRAM 2.5 KB (ATmega32U4)
EEPROM 1 KB (ATmega32U4)
Clock Speed 16 MHz
LED_BUILTIN 13
Length 48 mm
Width 18 mm
Weight 13 g
TT-ARS-A000093
in stock INR 2301
Arduino
1 1

ARDUINO MICRO WITHOUT HEADERS

Sku: TT-ARS-A000093
₹2,301


Sold By: tenettech
Features
  • Shipping in 10-12 Working days

Description of product

The Micro is a microcontroller board based on the ATmega32U4 (datasheet), developed in conjunction with Adafruit. It has 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a micro USB connection, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a micro USB cable to get started. It has a form factor that enables it to be easily placed on a breadboard.

 The Micro board is similar to the Arduino Leonardo in that the ATmega32U4 has built-in USB communication, eliminating the need for a secondary processor. This allows the Micro to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial / COM port. It also has other implications for the behavior of the board.

Microcontroller ATmega32U4
Operating Voltage 5V
Input Voltage (recommended) 7-9V
Input Voltage (limit) 6-9V
Digital I/O Pins 20
PWM Channels 7
Analog Input Channels 12
DC Current per I/O Pin 20 mA
DC Current for 3.3V Pin 50 mA
Flash Memory 32 KB (ATmega32U4) of which 4 KB used by bootloader
SRAM 2.5 KB (ATmega32U4)
EEPROM 1 KB (ATmega32U4)
Clock Speed 16 MHz
LED_BUILTIN 13
Length 48 mm
Width 18 mm
Weight 13 g
