Series | AS |
Product Status | Active |
Technology | Magnetic |
Type | General Purpose |
Frequency Range | 380 Hz ~ 7.5 kHz |
Frequency - Self Resonant | 380Hz |
Impedance | 8 Ohms |
Efficiency - dBA | 84.00 |
Efficiency - Testing | 1W/1M |
Efficiency - Type | Sound Pressure Level (SPL) |
Power - Rated | 500 mW |
Power - Max | 800 mW |
Port Location | Top |
Shape | Round |
Material - Cone | Polyester, Polyethylene Terephthalate (PET) |
Material - Magnet | Ferrite |
Ingress Protection | - |
Ratings | - |
Termination | Solder Eyelet(s) |
Size / Dimension | 2.598" Dia (66.00mm) |
Height - Seated (Max) | 0.492" (12.50mm) |
Series | AS |
Product Status | Active |
Technology | Magnetic |
Type | General Purpose |
Frequency Range | 380 Hz ~ 7.5 kHz |
Frequency - Self Resonant | 380Hz |
Impedance | 8 Ohms |
Efficiency - dBA | 84.00 |
Efficiency - Testing | 1W/1M |
Efficiency - Type | Sound Pressure Level (SPL) |
Power - Rated | 500 mW |
Power - Max | 800 mW |
Port Location | Top |
Shape | Round |
Material - Cone | Polyester, Polyethylene Terephthalate (PET) |
Material - Magnet | Ferrite |
Ingress Protection | - |
Ratings | - |
Termination | Solder Eyelet(s) |
Size / Dimension | 2.598" Dia (66.00mm) |
Height - Seated (Max) | 0.492" (12.50mm) |
