Series | ASMB-UTF2 |
Product Status | Active |
Color | Red, Green, Blue (RGB) |
Configuration | Independent |
Lens Color | - |
Lens Transparency | Diffused |
Millicandela Rating | 690mcd Red, 1850mcd Green, 400mcd Blue |
Lens Style | Oval with Flat Top |
Lens Size | - |
Voltage - Forward (Vf) (Typ) | 2V Red, 3.1V Green, 3.1V Blue |
Current - Test | 20mA Red, 20mA Green, 20mA Blue |
Viewing Angle | 110° |
Mounting Type | Surface Mount |
Wavelength - Dominant | 620nm Red, 524nm Green, 471nm Blue |
Wavelength - Peak | 628nm Red, 518nm Green, 467nm Blue |
Features | - |
Package / Case | 6-SMD, J-Lead |
Supplier Device Package | 6-PLCC |
Size / Dimension | 2.80mm L x 2.70mm W |
Height (Max) | 2.60mm |
Series | ASMB-UTF2 |
Product Status | Active |
Color | Red, Green, Blue (RGB) |
Configuration | Independent |
Lens Color | - |
Lens Transparency | Diffused |
Millicandela Rating | 690mcd Red, 1850mcd Green, 400mcd Blue |
Lens Style | Oval with Flat Top |
Lens Size | - |
Voltage - Forward (Vf) (Typ) | 2V Red, 3.1V Green, 3.1V Blue |
Current - Test | 20mA Red, 20mA Green, 20mA Blue |
Viewing Angle | 110° |
Mounting Type | Surface Mount |
Wavelength - Dominant | 620nm Red, 524nm Green, 471nm Blue |
Wavelength - Peak | 628nm Red, 518nm Green, 467nm Blue |
Features | - |
Package / Case | 6-SMD, J-Lead |
Supplier Device Package | 6-PLCC |
Size / Dimension | 2.80mm L x 2.70mm W |
Height (Max) | 2.60mm |
